Introduction to proxysnr • proxysnr

library(proxysnr)
library(magrittr)

Getting started

With proxysnr you can apply spectral analyses to climate proxy records that were obtained from a spatial array of proxy observation locations, e.g. ice cores, marine sediment cores, tree rings, etc., to derive the power spectral density (PSD, or, in short, spectrum) of the record’s common signal and the PSD of the local noise (for details see Münch and Laepple, 2018)

To work with proxysnr, supply the proxy records in form of a list, or a data frame, with each list element or data column representing one of the proxy observation locations, where the proxy data were sampled over time, depth, or any other given variable, at equal intervals. Note that the equidistance of the sampling intervals is mandatory to obtain correct spectra.

To showcase the analyses available with proxysnr we create an artifical proxy dataset which mimicks five observation locations, each sampling the proxy data at 1000 sampling points:

set.seed(20241030)

# five "cores" (proxy observation locations)
nc <- 5
# number of sampling points (e.g. time steps) at each location
nt <- 1000

# simulate a common climate signal as an AR-1 process
clim <- as.numeric(arima.sim(model = list(ar = 0.7), n = nt))
# simulate the independent proxy noise as a white noise process
noise <- as.data.frame(replicate(nc, rnorm(n = nt, sd = 1.5)))

# create a data frame (i.e. a "spatial array") of five "cores" that record the
# same climate signal (scaled to make it relatively a bit stronger) but
# independent noise
cores <- 1.2 * clim + noise

Obtaining and plotting the proxy array spectra

A first step is to calculate the PSD for each proxy record, obtain the average spectrum of these individual spectra, and get the spectrum of the data series when averaging across all proxy records (the “stacked” record); all of which is handled by the function ObtainArraySpectra(). We only need to set the sampling resolution via the parameter res (chosen arbitrarily here) in order to obtain the correct spectral units, and we can apply some smoothing to the raw spectral estimates (parameter df.log) to reduce their spectral uncertainty:

arrspec <- ObtainArraySpectra(cores, res = 2, df.log = 0.1)

names(arrspec)
#> [1] "single" "mean"   "stack"
attr(arrspec, "array.par")
#>   nc   nt  res
#>    5 1000    2

The output list contains the attribute array.par which stores information on the underlying proxy record array, namely the number of records (“nc”), the number of sampling points per record (“nt”), and the sampling resolution (“res”), so that other proxysnr functions have these information available.

The function PlotArraySpectra() directly plots the results:

PlotArraySpectra(arrspec, remove = 0, xlim = c(2000, 2), ylim = c(0.05, 50),
                 xlab = "Period (a.u.)", ylab = "Power spectral density")

The plot displays the spectra as a function of the inverse spectral frequency, e.g. time period, which is often more intuitive to interpret. Each proxy record’s spectrum is shown as a thin grey line (however, you can change all colours to your likings), and the mean spectrum of all individual spectra is plotted as the thick black line, which averages out some spectral uncertainty of the individual spectra and thus delivers a more accurate representation of the average proxy PSD. If all proxy record variations were indepedent noise, the spectrum of the stacked record (thick brown line) would follow the line of the mean spectrum divided by the number of records, i.e. the black dashed line on the plot. Hence, the PSD of the spectrum of the stacked record which exceeds this line (the blue shaded area) results from proxy variability common to all records, while the spectral energy which is lost (the red shaded area) represents independent noise variability.

When you do not need to save the intermediate results, you can also pipe the workflow,

cores %>%
  ObtainArraySpectra(res = 2, df.log = 0.1) %>%
  PlotArraySpectra(remove = 0, xlim = c(2000, 2), ylim = c(0.05, 50),
                   xlab = "Period (a.u.)", ylab = "Power spectral density")

and in the following we always show the combined, piped workflow in order to highlight how the proxysnr functions are linked.

Signal and noise spectra

While the previous plot is visually insightful, the blue and red shaded areas are only proportional to the actual signal and noise spectra (see Münch and Laepple, 2018 for details); these are instead calculated using SeparateSignalFromNoise() which delivers also the spectrum of the signal-to-noise ratio, which is an important quantity to interpret proxy variability in terms of climate variability.

spec <- cores %>%
  ObtainArraySpectra(res = 2, df.log = 0.1) %>%
  SeparateSignalFromNoise()

str(spec)
#> List of 3
#>  $ signal:List of 2
#>   ..$ freq: num [1:500] 0.0005 0.001 0.0015 0.002 0.0025 0.003 0.0035 0.004 0.0045 0.005 ...
#>   ..$ spec: num [1:500] 8.21 13.57 19.86 38.26 44.7 ...
#>   ..- attr(*, "class")= chr "spec"
#>  $ noise :List of 2
#>   ..$ freq: num [1:500] 0.0005 0.001 0.0015 0.002 0.0025 0.003 0.0035 0.004 0.0045 0.005 ...
#>   ..$ spec: num [1:500] 1.56 3.04 3.72 4.03 4.04 ...
#>   ..- attr(*, "class")= chr "spec"
#>  $ snr   :List of 2
#>   ..$ freq: num [1:500] 0.0005 0.001 0.0015 0.002 0.0025 0.003 0.0035 0.004 0.0045 0.005 ...
#>   ..$ spec: num [1:500] 5.26 4.47 5.33 9.5 11.08 ...
#>   ..- attr(*, "class")= chr "spec"
#>  - attr(*, "array.par")= Named num [1:3] 5 1000 2
#>   ..- attr(*, "names")= chr [1:3] "nc" "nt" "res"

There are two plotting routines available in proxysnr, LPlot() and LLines(), to plot any spectral object returned by its functions automatically on double-logarithmic axes. These follow the concept of base R’s plot() and lines() functions and can thus make a fresh spectrum plot or add a spectrum to an existing plot. So to plot the results from our analyses in spec we can write

op <- par(mar = c(5, 5, 0.5, 0.5), las = 1,
          cex.main = 1.5, cex.lab = 1.5, cex.axis = 1.25)

LPlot(spec$signal, inverse = TRUE,
      xlab = "Period (a.u.)", ylab = "Power spectral density",
      xlim = c(2000, 2), ylim = c(0.1, 50), col = "dodgerblue4", lwd = 2)
LLines(spec$noise, inverse = TRUE, col = "firebrick4", lwd = 2)
legend("bottomleft", c("Signal", "Noise"), col = c("dodgerblue4", "firebrick4"),
       lty = 1, lwd = 2, bty = "n")

LPlot(spec$snr, inverse = TRUE, xlab = "Period (a.u.)", ylab = "SNR",
      xlim = c(2000, 2), ylim = c(0.1, 50), col = "black", lwd = 2)

par(op)

We can test whether the estimated noise spectrum indeed reproduces the standard deviation of 1.5 of the given white noise process:

df <- diff(spec$noise$freq)[1]
sqrt(2 * df * sum(spec$noise$spec)) # ok!
#> [1] 1.497102

Estimating confidence intervals

Since confidence intervals for the signal, noise, and SNR spectra cannot be obtained analytically, proxysnr offers to estimate these from a parametric bootstrapping procedure based on Monte Carlo simulation of surrogate data:

spec <- cores %>%
  ObtainArraySpectra(res = 2, df.log = 0.1) %>%
  SeparateSignalFromNoise() %>%
  EstimateCI(nmc = 10, df.log = 0.1, ci.df.log = 0.05)

The plotting routines LPlot() and LLines() automatically add a shading for the confidence intervals to the plot, when such are available, so the same above plotting code can be used to reproduce the plots now including the only just estimated confidence intervals:

Correction of signal and noise spectra

During archiving, the proxy records may be subject to smoothing, e.g. in firn and ice by diffusion, or in marine sediments by bioturbation. Furthermore, if the proxy records are dated their chronologies may be uncertain between the records, with this time uncertainty affecting the reconstruction of the common signal.

proxysnr offers to correct the estimated signal and noise spectra for these effects by supplying respective transfer functions to SeparateSignalFromNoise() via the function parameters diffusion and time.uncertainty. These transfer functions describe the loss in spectral power due to the smoothing or the uncertain chronologies and need to be assessed and provided by the user.

For two special cases you can apply proxysnr to directly calculate the transfer functions: firn diffusion (function CalculateDiffusionTF()) and time uncertainty in layer-counted chronologies (function CalculateTimeUncertaintyTF()); see also Münch and Laepple (2018) for more details on the processes and the implemented estimation, and the vignette("calculate-transfer-functions") for details on using the two functions.

Proxy records also contain measurement noise. If you have an estimate of its magnitude and its spectral shape, you can supply these information to SeparateSignalFromNoise() via the measurement.noise parameter, and the returned noise and SNR spectra will be corrected for the measurement noise, i.e. they will take into account only the proxy-specific noise that was created during the archiving process.

Further analysis options

There are some more proxysnr functions you can use to conduct and visualise analyses:

GetIntegratedSNR() delivers the ratio of the integrated signal and noise spectra, which corresponds to the SNR at a specific sampling resolution;
ObtainStackCorrelation() calculates the expected correlation of a stack of proxy records with the common climate signal as a function of the number of records averaged and the records’ sampling resolution (see Fig. 4 in Münch and Laepple, 2018 for an example);
PlotStackCorrelation() to directly plot the output from ObtainStackCorrelation();
PlotSNR() to plot several SNR datasets in one figure;
PlotTF() to make a plot of the transfer functions obtained with CalculateDiffusionTF() and/or CalculateTimeUncertaintyTF().

Package data

proxysnr ships with four package datasets:

?dml contains the oxygen isotope data of 15 firn cores from Dronning Maud Land (DML), Antarctica (Graf et al., 2002);
?wais contains the oxygen isotope data of 5 firn cores from the West Antarctic Ice Sheet (WAIS; Steig, 2013);
?diffusion.tf contains pre-calculated diffusion transfer functions for the DML and WAIS isotope records; and
?time.uncertainty.tf contains pre-calculated time uncertainty transfer functions for these records.

The datasets can be used to test out the functions from proxysnr, and they have been the basis for the analyses in Münch and Laepple (2018); see also the vignette("plot-muench-laepple-figures") for reproducing their results.

References

Graf, W., et al.: Stable-isotope records from Dronning Maud Land, Antarctica, PANGAEA, doi: 10.1594/PANGAEA.728240, 2002.

Münch, T. and Laepple, T.: What climate signal is contained in decadal- to centennial-scale isotope variations from Antarctic ice cores?, Clim. Past, 14, 2053-2070, doi: 10.5194/cp-14-2053-2018, 2018.

Steig, E. J.: West Antarctica Ice Core and Climate Model Data, U.S. Antarctic Program (USAP) Data Center, doi: 10.7265/N5QJ7F8B, 2013.
